Design your rack before you build it.
The complete planner for IEM, playback and touring audio racks — free, in your browser.
- 329Components
- 96Brands
- 36Categories
- FreeNo account needed
A complete catalog of real gear.
Not a box-drawing tool with generic rectangles. Every unit is a real product, with the dimensions, the power draw and the exact ports on the back.
Search 329 components, not categories.
Browse by group, filter by brand, price or the gear you already own — or just start typing. The search survives a typo, so “sennnheiser” still finds the Sennheisers.
Search Anything…
Owned 9Brand
All brands
Max price
Any
Sort by
Category
Favorites
Behringer X32 Rack Digital Mixer
3U
Recently used
Shure PSM1000 Dual Transmitter
1U
Wireless & RF87
IEM Transmitter · IEM Receiver · Wireless Mic
Mixing & I/O82
Digital Mixer · Audio Interface · Stage Box
Snakes & Splits39
Analog Snake · Splitter · DI Box
Monitoring26
Personal Mixer · Headphone Amp · Earphones / IEMs
Networking & Digital24
Network Switch · WiFi Router · Dante Converter
Not in the catalog? It will be in a minute.
Search for something we do not have yet and the dead end turns into an offer. Describe the unit and AI builds it — chassis, faceplate, rack units, power draw and a full port map — then drops it straight into your rack.
Every one gets flagged for review, so the next person searching for it just finds it.
Mackie HM-800 8-Channel Headphone Amplifier
Brand
All brands
Max price
Any
Sort by
Category
Not in the catalog — want us to build it?
Mackie HM-800 8-Channel Headphone Amplifier
Builds the chassis, faceplate, ports and power draw — then adds it to your rack.
The brands you already own.
96 manufacturers, from the Behringer in the back of the van to the Wisycom in the flight case. Filter to one brand and see everything of theirs we hold.
Brand
APC
Max price
Any
Sort by
Category
64 Audio
Ableton
AC Infinity
Allen & Heath
Antelope Audio
APC
API
Apple
ART
ASUS
Audinate
+85 more
Every spec the plan depends on.
Rack units, weight, power draw, port map, street price. This is the data the bill of materials totals, the power calculation warns on, and the health check reads when it tells you something will not fit.
Digital Mixer
Behringer X32 Rack Digital Mixer
$989
- Rack units
- 3U
- Depth
- 287 mm
- Weight
- 6.7 kg
- Power draw
- 80 W
- Peak draw
- 100 W
- Ports
- 54
Feeds BOM · power · health
Wire the whole rack. See the whole signal.
The back of the rack is where a plan stops being a shopping list and starts being a rig.
Every cable, drawn where it actually goes.
Flip to Back View and the rear panels are the real ones — the actual jacks, in the actual positions. Drag from one to another and you have a connection, coloured by signal type: green for analog audio, red for power, on down the legend.
Analog AudioPower (AC)Digital Audio
Or let auto-wire take the first pass.
Auto-wire reads the rack and proposes the patch — IEMs to their transmitters, mixer to the splitter, everything to power. You approve a preview before a single cable lands, and anything it got wrong is one drag from fixed.
Auto-wire
12 connections- Snare SplitX32 Rack · in 2
- Kick SplitX32 Rack · in 1
- X32 out L/RPSM1000 · TX1 in
- PL-Plus DMCX32 Rack · IEC
- +8 more
CancelApply
Label the ports the way your crew says them.
Rename any jack to what it actually carries — Kick, Snare Split, IEM 3 — and tape it a colour. Those labels ride the rack into every view and out the other side onto the patch sheet.
Rear panel · labelled
KISSOHBSV1V2LR
Kick
XLR Female · Analog Audio · Input
Tape colour
Edit your rig by describing the change.
“Add a PSM1000.” “Remove one of the Sennheiser IEMs.” “Wire it up.” Type the change and watch it happen to the rack in front of you.
Edit your rig with AI
Tell your rig what to change — “add a PSM1000”, “remove one of the Sennheiser IEMs”, “wire it up”
Add a second X32 and wire it as the backup
Enter to apply · Shift+Enter for a new lineApply
Click any jack and get the whole story.
Connector, direction, signal type, channel count, which face it is on, what it draws in phantom power — plus what is on the other end of the cable, and a way to follow it there.
Port inspector
KI
Kick
Behringer X32 Rack · slot 2
Connected to
Kick · X32 RackSnare Split · SA-RMSS
- Connector
- XLR Female
- Direction
- Input
- Signal
- Analog Audio
- Channels
- 1
- Face
- Rear
- Phantom draw
- 10 mA
It's a playground.
There is no blank-page problem here. Start from the rack you already own, from a template, from a sentence — or from nothing at all.
Everything else in the case.
+1 wire
2m ago · 12 gear · 10 wires
+6 gear · −4 wires
3m ago · 12 gear · 9 wires
Edited rig
12m ago · 6 gear · 13 wires
Version history
Every change is a version. Scrub back through the timeline and restore any of them — restoring never loses work, because the state you are leaving is saved too.
PaintMetalWearStickers
Make it yours
Paint the case, choose the metal, add road wear, cover it in stickers. The rack that comes out looks like a rack you own.
X32 Rack
PSM1000
SA-RMSS
Simplified mode
Detailed faceplates are the default. Switch to gear labels instead when you want the plan to read as a plan.
Behringer X32 Rack Digital Mixer$989
Shure PSM1000 Dual Transmitter$3,899
Furman PL-Plus DMC Power Conditioner$399
Total$5,287
SharePublishPDF
Bill of materials
Every unit, every price, one total — with share, publish and PDF export in the same panel.
Rack over capacity by 1UShow me
Peak draw exceeds 15A dropShow me
IEM 3 output wired to nothingShow me
Rig health
Continuous checks for the things that bite: a unit that will not fit, power you do not have, a jack wired to nothing. Click a finding and it spotlights the exact jack.
Rack
9U / 16U
Est. cost
$10,885
Power
180 W
Weight
54 lb
Rig summary
Rack units used, estimated cost, peak power draw and total weight — live, in the corner of the canvas.
Browse the catalog.
Every component has its own page with full ports, weight, power draw and pricing — fully indexed, so a search for “Shure PSM1000 setup” or “Allen & Heath dLive C2500 ports” lands directly on the answer.
Learn the craft.
Free guides on rack design fundamentals: how audio flows through an IEM rack, how to plan power, what a touring-grade signal path looks like in 2026.
Guide
IEM Rig Basics: A Beginner’s Guide to In-Ear Monitor Systems
What an IEM rig actually is, the components that go into one, and how to plan your first one without overspending or blowing a circuit.
Guide
Going From Wedges to In-Ears: A Band’s Step-By-Step Transition Plan
A plain-English plan for bands switching from floor wedges to in-ear monitors — what to buy, what to expect at the first rehearsal, and how to not hate it.
Guide
From Stage to Ear: How Audio Flows Through an IEM Rack
A walking tour of the signal path from microphone to in-ear monitor, with what every box in the rack actually does to the audio along the way.
Frequently asked questions.
Is IEM Rig free to use?
Yes. The full planner — drag-and-drop, auto-wire, signal flow, power and weight calculation, PDF export — is free, no account needed. A free account adds cloud sync for up to 3 rigs, and IEM Rig Pro adds more rigs, branded exports, and a bigger AI allowance.
Do I have to install anything?
No. IEM Rig runs entirely in the browser. You can also install it as a Progressive Web App (PWA) on iOS, Android, and desktop for a native-app experience offline.
What gear is in the catalog?
329 components from 96 manufacturers across 36 categories — wireless IEM systems, digital mixers, stage boxes, audio interfaces, antenna distros, power conditioners, splitters, and more.
Can I share my rig with my team?
Yes. Every rig has a shareable link, and signed-in users can publish rigs to the public gallery at /g for the rest of the community to view, remix, and learn from.
Does it work on mobile?
Yes. The mobile UI is a first-class experience: pinch to zoom the rack, single-finger pan, tap-and-hold to drag gear, and bottom-sheet drawers for catalog browsing. Install it to your home screen for offline access.
Can I import an existing rack design?
Yes — point your phone camera at your physical rack and the AI scan feature identifies the gear and assembles a starter design you can edit. It also captures wiring intent so signal flow is mostly there before you start adjusting.
Start planning your rack today.
No account, no trial, no cap. Open the planner and put the first piece of gear in the rack.
