Sennheiser AD 3700 Active Directional Antenna
Power arrives through a documented signal or data connection.
- Arrives through
- No documented input
- This stage
- Performs the documented product role
- Power
- Bus
RF Antenna
Sennheiser AD 3700 Active Directional Antenna
The AD 3700 is Sennheiser's flagship receive paddle: a wideband directional antenna with the AB 3700 booster built into the housing, so long coax runs back to a Digital 6000 or 2000-series rack stop costing you signal. The four-position amplifier (bypass to +15 dB) exists to offset cable loss, with an LED that color-codes the current setting from across the stage. It draws bias power over the same BNC feed from the receiver or antenna distribution, keeping the remote end a single cable.
