Power Conditioner
The Furman PL-Plus DMC is a rack staple that cleans up your AC power while giving you real-time voltage and current monitoring via its front panel meters. The pull-out rack lights are genuinely useful for dark stage-side setups, and the linear filtering protects sensitive audio and digital gear from power line noise. A smart first-piece-in for any IEM or playback rack build.
Manufacturer product photography — the drawn faceplate stays true to panel layout; these show the hardware itself.
01 · What it does—and what that changes in your rig.
Start with the payoff, then work through how it functions, where it fits, and the details that change a real build.
Every rack gets its power from somewhere, and the PL-Plus DMC is the classic answer to making that somewhere trustworthy. It sits at the top of the rack doing three jobs: series-mode surge suppression and EMI/RFI filtering for everything downstream, a voltmeter/ammeter you can read from across the stage, and the signature Furman pull-out LED rack lights that have located a thousand loose XLRsThe standard 3-pin locking connector for mics and balanced line signals — pin 1 is the shield, pins 2 and 3 carry the balanced pair. in dark corners.
The digital meter is the part touring users actually rely on. Walking into a venue and watching the mains sag to 108V under load — or ride up hot on a generator — before your mixers and transmitters find out is exactly the kind of cheap insurance a rig needs. The current readout earns its keep at plan time too: add up your rack's draw in this app, then confirm reality against the meter at soundcheck.
Be clear about what it is not: a power conditionerFilters venue AC, clamps surges, and gives the rack one tidy inlet. Not a voltage regulator and not a battery — just cleaner power. is not a UPSUninterruptible Power Supply — a battery that rides the rig through brownouts and generator hiccups so computers never reboot mid-song. and not a voltage regulatorActively holds the output at a steady 120 V while venue power sags or spikes — a step beyond filtering, one short of a battery.. A brownout will still sag through it, and a dropoutA brief audio gap when the radio link fails — the thing diversity, distros, and coordination all exist to prevent. will still drop your digital consoles — if the rig has computers or a digital mixer that must survive a two-second generator transfer, budget a UPS below this unit and feed the critical gear from that. Conditioner for the analog and RFRadio Frequency — the wireless part of wireless. RF planning is why big rigs scan, coordinate, and combine antennas instead of hoping., UPS for the brains, is the standard stack.
02 · Know the whole path before you buy.
Learn the route as a block diagram: source, product function, transport, and destination. Select any block to see what enters, what changes, and what leaves.
Each block answers the same three questions: what arrives, what changes here, and what leaves.
nema 5 15
03 · What this product asks of the rest of the system.
Treat connector names as the start of the check—not the answer. These are the boundaries that determine a complete working path.
Use it when 1U and 266.7 mm of depth fit the case.
Complete the path with upstream and downstream gear that matches connector, direction, signal type, protocol, and wiring standard.
Documented connectors: nema 5 15, bnc. Match connector, direction, and signal type—not shape alone.
04 · Every connector, grouped by job.
Switch the product view and the documented port inventory updates with it—hardware and data stay side by side.
Switch panels to keep the hardware view and the documented port list in sync.
| Port | Panel | Connector | Direction | Signal | Channels |
|---|---|---|---|---|---|
| POWER CABLE | rear | nema 5 15 | input | power | — |
| OUTLET 1 | rear | nema 5 15 | output | power | — |
| OUTLET 2 | rear | nema 5 15 | output | power | — |
| OUTLET 3 | rear | nema 5 15 | output | power | — |
| OUTLET 4 | rear | nema 5 15 | output | power | — |
| OUTLET 5 | rear | nema 5 15 | output | power | — |
| OUTLET 6 | rear | nema 5 15 | output | power | — |
| OUTLET 7 | rear | nema 5 15 | output | power | — |
| OUTLET 8 | rear | nema 5 15 | output | power | — |
| FRONT OUTLET | front | nema 5 15 | output | power | — |
| LAMP | rear | bnc | output | analog audio | — |
Showing 11 of 11 documented physical ports. Scroll to review the remaining rows.
05 · Compare the decision, not just the price.
The rows are organized around fit, power, I/O, and system role so a cheaper unit cannot hide a more expensive workflow.
| Compare |  |  |  |  |
|---|---|---|---|---|
| Fit | 📐 1U | 📐 1U | 📐 1U | 📐 1U |
| Power | ⚡ Unverified | ⚡ Unverified | ⚡ Unverified | ⚡ Unverified |
| Weight | ⚖️ 11.0 lb | ⚖️ 6.0 lb | ⚖️ 4.4 lb | ⚖️ 7.9 lb |
| I/O | 🔌 11 | 🔌 10 | 🔌 10 | 🔌 9 |
| Estimate | 💵 ~$399 | 💵 ~$149 | 💵 ~$99 | 💵 ~$299 |
| Deep dive | Current selection | Full comparison → | Full comparison → | Full comparison → |
06 · Resolve the questions that can change the purchase or build plan.
Short, source-backed answers surface rack fit, power, cabling, and connection details before they become surprises.
It occupies 1U. Its documented depth is 266.7 mm.
Its power requirement is not yet verified in the catalog.
11 documented physical ports, including POWER CABLE, OUTLET 1, OUTLET 2, OUTLET 3, OUTLET 4, OUTLET 5.
